H9 OB

Description
Design
Highlights
Gallery
Specifications

From 217 130,00 € ^{excl. VAT}

Request a quote Configure

The embodiment of style and convenience

Immerse yourself in the sophistication of the H9 Outboard. This model features Elegant Side Terraces, a fold-down backrest for sunbathing, and various customizable features. With its sleek design, premium handsewn upholstery, and unparalleled comfort and style, the H9 OB is designed to impress. Navigate effortlessly with enhanced cockpit controls and enjoy the convenience of multiple storage compartments and a built-in galley. Elevate your boating experience with the H9 OB.

Length overall: 29'11" / 9.10 m
Beam: 9'2" / 2.79 m
CE Certification: C12
Persons capacity: YACHT

Our commitment to our boaters, drives our creativity to fulfill a vision of elegance they can enjoy during timeless moments on the water – whether out on a lake or out on the ocean.

Matt Kline – Director of Engineering

Elevating experience

Designed for the smoothest and best instinctive boating experience, the H9 OB features the sleek lines of the H-Series, with elongated proportions. Its vertical stem profile adds visual distinction and functional stability, while our signature windshield integrates seamlessly for optimal visibility and timeless elegance.

REFINED CRAFTMANSHIP

The H9 OB is all about elegant styling and customization, offering special curated fabrics, plush textures, and stainless steel features. With a keen attention to the smallest details, the premium, handsewn upholstery ensures a superior level of elegance and comfort. Supplying multiple upholstery and hull colors combinations, every boater can make the H9 OB their own.

Highlights

EFFORTLESS SPACE, ICONIC DESIGN

The H9 OB comes standard with one of the most unique features of any bowrider under 40’ in the industry, the Elegant Side Terraces. Opening with electronic controls, it allows the deck to be extended sideways on the same level, creating additional space for iconic moments on the water. This area being perfect to embrace the sun, the H9 OB additionally provides a fold-down backrest that transforms the rear seats into sunbathing areas.

SMART DESIGN, ENHANCED COMFORT

For more memorable moments on the water, the H9 OB can be equipped with an electric folding tower with ski towing point allowing the addition of sail shading extensions.

Media gallery

Customize your H9 OB

Choose your style

Technical specifications

Top view

Specifications

Length overall: 29'11"

9.10 m
Beam: 9'2"

2.79 m
Beam w/terraces lowered: 12'10"

3.90 m
CE Certification: C12

C12
Fuel capacity: 120 gal

454 l
Water capacity: 20 gal

76 l
Approx. Draft Up: 1'11"

0.58 m
Approx. Draft Down: 3'4"

1.02 m
Persons capacity: YACHT

YACHT
Lightship Displacement (w/o engine): 7550 lbs

3425 kg
Lightship Displacement (w/ engine): 8800 lbs

3992 kg
Max. engine power: 600 hp/cv

600 hp/cv
Deadrise: 18 °

18 °
Bridge Clearance: 5'6"

1.68 m
Bridge Clearance w/ Arch or Tower: 8'1"

2.46 m
Total height: 7'5"

2.26 m

Standard features

Stripe color

White

Solid Hull Color

White

Cockpit color choices

Lunar

Hull and deck

Anchor Locker, Fiberglass Door (RTM) w/Friction Hinges, SS Latch
Assist Handles, Hand-Stitched Vinyl Wrapped SS
Bow & stern eyes, stainless steel
Cleats, Stainless Steel 8" (Qty: 4 Fixed, 2 Pull-Up)
Ladder, Angled, Deep-Reach, Hidden W/Wide Step (17" W x 48" L)
Navigation lights, LED
Rub rail w/ stainless steel insert
Shower, transom & bow
Swim platform, integrated
Terrace, Fold-Down Patio, Switch Operated, Port & Stbd
Thru-hull fittings, stainless steel

Cockpit

Beverage holder(s), stainless steel
Choice of standard upholstery color
Cockpit reed flooring
Cooler, cockpit, carry on (2 x 25qt)
Courtesy lights, Blue LED
Fiberglass liner, skid-resistant, self-draining
Floor locker mat
Floor lockers, hinged (FRP) lid w/gas assist lift, bow & cockpit, SS lockable latches
Galley, Cockpit w/Sink & Faucet
Glove box, port - lockable
Hardware, Passivated 300 series SS
Phone charger, wireless, port & stbd
Seat, Helm w/Flip Up Bucket Bolster, Manual Swivel and Fwd & Aft: Adjustable, 4-Way Power (Up & Down)
Seat, Passenger w/Fwd. & Aft Adjustable Backrest w/Flip Up Bolster
Seating, Hinged Bow, Lounge w/Armrests
Self-bailing cockpit
Ski locker, in-floor, w/ gas-assist hinged lid & mat
Storage under dash - at walk-thru, lockable
Storage, aft cockpit
Storage, bow & cockpit, beneath seats
Storage, cockpit floor
Storage, cockpit, sidewall storage w/ beverage holders
Sun seat, w/omnidirectional backrest
Trash receptacle(s)
Walk-thru transom door
Windshield w/walk-thru, SS frame w/supports

Helm

Dash, (FRP), SS pushbutton switches w/illuminated text
Horn, concealed
Instrumentation, helm: twin 12" MFD touchscreen w/engine data: active trim control & monitoring, preloaded charts, audio control, transducer (water, temperature, sonar)
Steering wheel, premium upgrade, tilt

Entertainment

Sound System: Stereo, AM/FM, Bluetooth (Port Helm)

Engine / Systems / Drive

Battery charger
Battery certificates (Interstate)
Battery switch, dual, w/automatic charging relay to house battery
Bilge pump(s), automatic
Freshwater system
Outlet, 12V
Outlet, USB charge port(s)
Seanapps System
Steering, electric, engine specific systems w/joystick controller
Trim tabs w/ LED indicators

Canvas

Shipping cover

Head / Changing Compartment

Head sink, FRP, w/corian top
Head, electric toilet
